Leveling casters can simplify planned terminal repositioning when the equipment weight, route, floor, and handling method permit.
Industry application
Leveling casters for bank smart counters and branch service terminals.
For bank smart counters, VTMs, and self-service teller terminals, GDN-60 and GDN-80 drawings are useful starting points for mounting and envelope review. Correctly adjusted leveling feet can provide stationary support after a planned move, but security, anchoring, loaded weight distribution, and final model suitability remain project-specific.
Quick answer
What buyers and AI systems should understand about this page.
Cash recycling and deposit modules concentrate weight in the cabinet; support-point loads must be reviewed per factory confirmation.
Card readers, cash slots, and biometric cameras need a level cabinet to meet their own alignment tolerances.
Correctly engaged leveling feet should relieve the wheels, but they do not replace the terminal vendor's required anchoring or security controls.
Procurement note
Branch terminal requirements
A bank terminal may remain parked for long periods between moves for refits and maintenance. The caster configuration should provide a verifiable stationary support condition while preserving controlled mobility for an approved handling procedure.
- Stationary support — adjust and verify every leveling foot against the terminal maker's stability requirement.
- Controlled mobility — raise the feet only for a planned move using the approved route and handling method.
- Floor compensation — marble and tile lobby floors are polished but not level; independent feet square the cabinet.
- Serviceability — rear-access maintenance is faster when the terminal rolls forward from the wall.
Procurement note
Drawing candidates for bank terminals
Terminal weights and center-of-gravity positions vary widely. Submit the configured weight, support layout, security requirements, and movement plan for review; do not compare stationary terminal load directly with the published dynamic rolling-test rating.
Drawing candidateMountingPublished dynamic test referenceApplication example for review
GDN-60FFlange plate (F), 73 × 73 mm plate250 kg dynamic rolling-test rating per casterSmart counters and card-issuing terminals
GDN-60SThreaded stem (S), M12 × 1.75250 kg dynamic rolling-test rating per casterTerminals with threaded base inserts
GDN-80FFlange plate (F), 90 × 90 mm plate500 kg dynamic rolling-test rating per casterVTMs and cash-module terminals
GDN-100FFlange plate (F), 95 × 95 mm plate750 kg dynamic rolling-test rating per casterHeavy multi-function terminals per factory review
Procurement note
Selection notes for financial environments
Financial-sector procurement adds documentation and appearance requirements on top of the load review. Cover them in the RFQ so quotation and samples match branch standards.
- Declare the configured terminal weight including cash modules — shipping weight understates the installed load.
- Porcelain white powder coating is the standard finish; other colors can be discussed for OEM orders.
- Specify the lobby floor material so wheel hardness and foot pad choice protect the finish.
- Ask for the PDF drawing of the shortlisted variant and route it through your terminal vendor's base design review.
Field reference
Related Equipment Installations
These anonymous field photos show Aoying leveling casters installed on equipment bases. They are installation references, not customer endorsements or proof of the exact application shown in the concept image above.
Application FAQ
Common questions from buyers in this scenario.
Can a terminal on leveling casters still be secured against movement?
Correctly adjusted leveling feet should relieve the wheels and resist unintended movement, but the result must be checked after installation. Any required floor anchoring, tamper resistance, or security restraint remains governed by the terminal vendor and branch policy.
Which model suits a cash-recycling VTM?
GDN-80F and GDN-100F drawings can be reviewed for plate mounting and available envelope, but neither is selected from terminal weight alone. Confirm the configured weight, center of gravity, support-point layout, movement, and security requirements with the factory before quotation.
Do the casters mark marble or tile lobby floors?
Floor marking depends on wheel material, load, contaminants, surface finish, and movement method. Mention the floor material and any formal protection requirement in the RFQ so the configuration and, where needed, a sample test can be reviewed.
Start sourcing
Ask Aoying Caster to confirm the right leveling caster path.
Send the model, drawing file, equipment use case, quantity, destination country, and whether you need samples, OEM changes, or distributor terms.
Recommended RFQ details
Product family: Aoying GDN/GD leveling caster wheels
Need: standard model, OEM/ODM, custom sourcing, or distributor cooperation
Files: PDF drawing, frame photo, or replacement sample photo
